CYT1002AE single segment LED linear constant current Constant Power control chip

Update date：2024/3/5 Number of views：

Brand： CYT
model： CYT1002AE
market value： ~~0.9~~
concessional rate： 0.5

Trait：Input voltage: 120Vac/220VacSupport high PF solution: PF>0.9Support low PF solution: PF>0.5, no flickerOutput current bias between ICs<±5%Integrated 700V high-voltage MOS tube, canpass 700V lightning strike without anyprotection deviceNo magnetic components for EMI applicationsWith over temperature adjustmentWith constant power regulationPackage: ESOP8

Product introduction

CYT1002AE is a single segment LED linear constantcurrent control chip with constant power and highpower factor. It integrates 700V high voltage MOSFET,with superior resistance to avalanche breakdown andsurge. It can pass 700V lightning surge test when noprotection device in the periphery, and built-in over-temperature protection function to improve systemapplication reliability. The output current can beadjusted by adjusting the REXT on the periphery. Atthe same time, the CYT1002AE integrates the inputline voltage compensation function. When the inputline voltage is too high, CYT1002AE will reduce theoutput current according to the external compensationresistor to ensure that the input power does notchange with the line voltage.It is mainly used in the fields of LED lighting,architectural lighting engineering, etc. The systemstructure is simple, the peripheral components are few,the PCB traces are simple, and the solution cost islow.

Input voltage: 120Vac/220Vac

Support high PF solution: PF>0.9

Support low PF solution: PF>0.5, no flicker

Output current bias between ICs<±5% Integrated 700V high-voltage MOS tube, can pass 700V lightning strike without any protection device

No magnetic components for EMI applications

With over temperature adjustment

With constant power regulation

Package: ESOP8

Applications

LED fluorescent tube T5/T8

LED bulb

Projection lamp
