CYT1000AG Dual-channel linear constant current LED control chip

Update date：2024/3/5 Number of views：

Brand： CYT
model： CYT1000AG
market value： ~~0.6~~
concessional rate： 0.4

Trait：5mA to 120mA adjustable output current, accuracy ofconstant current can reach ±5%With over-temperature protection functionNo EMI problemChip and LED share aluminum substrateSimple circuit, cost-effectivePackage: ESOP8

Product introduction

CYT1000AG is a linear constant current IC with adjustable outputcurrent, high constant-current accuracy, simple applicationscheme. Cost and Resistance capacitance step-down arecomparable, with over-temperature protection function, safer andmore reliable.

5mA to 120mA adjustable output current, accuracy of

constant current can reach ±5%

With over-temperature protection function

No EMI problem

Chip and LED share aluminum substrate

Simple circuit, cost-effective

Package: ESOP8

Applications

LED bulb

LED fluorescent lamp

LED down lamp

LED ceiling light
