CYT3004BM Two stage Constant Power Linea LED Constant Current Control Chip

Update date：2024/3/6 Number of views：

Brand： CYT
model： CYT3004BM
market value： ~~0.8~~
concessional rate： 0.7

Trait：Few peripheral components, low solution cost Constant current control technology OUT port current is up to 65mA Output current error between chip and chip: < ±5% Input voltage: 220Vac Dual-channel progressive constant current method Accommodates a wide input voltage range of ±20% Input line network voltage compensation Over-temperature adjustment function Chip can share PCB board with LED Package: ESOP8

Product introduction

The CYT3004BM is a dual-channel progressive LEDlinear constant current control chip which usesconstant current control technology to precisely setthe LED current through external resistors.It integrates the input line network voltagecompensation function, which can maintain constantinput power by adjusting the output currentmagnitude through an external resistor within therated input voltage range.It has over temperature adjustment function toimprove the reliability of system. The system structureis simple, with few peripheral components and lowsolution cost.

Few peripheral components, low solution cost

Constant current control technology

OUT port current is up to 65mA

Output current error between chip and chip: < ±5%

Input voltage: 220Vac

Dual-channel progressive constant current method

Accommodates a wide input voltage range of ±20%

Input line network voltage compensation

Over-temperature adjustment function

Chip can share PCB board with LED

Package: ESOP8
